ALN - Alien


  • Green power saving feature

  • LED Display for Instant Status Indication

  • Simulated Sinewave Output

  • Fuse, Short Circuit, Overload Protections

  • Silent operation design

  • ALN-500VA

    •       　  　
     UPS
    Model
    ALN-500
    Capacity(VA)
    500 VA
    Capacity(Watts)
    250 W
    Form
    Disk Type

     INPUT
    Voltage
    220 / 230 / 240 Vac
    Voltage Range
    165 - 300 Vac
    Frequency Range
    50 / 60 Hz (Auto Sensing)

     OUTPUT
    Waveform
    Simulated Sine Wave
    Voltage
    220 / 230 / 240 Vac
    Frequency
    50 / 60 Hz ± 1 Hz
    Transfer Time
    2 - 4 ms(Typical)

     PROTECTION
    Full Protection
    Overload, Fuse, Short Circuit

     Battery
    Type
    6V 2.8Ah
    Quantity
    2
    Typical Recharge Time
    6 hours to 90%

     MANAGEMENT & COMMUNICATION
    Indicator
    LED Panel (Option)
    Communication Port
    USB B-type

     PHYSICAL
    Dimensions(WxDxH)(mm)
    148.5 x 220 x 42
    Weights(Kgs)
    2.3
    Shipping Dimensions(mm)
    288 x 205 x 98
    Shipping Weights(Kgs)
    2.7

     Alarm
    Overload / Fault
    Continuous Beeping
    Battery Mode
    Beep every 4 seconds
    Low Battery
    Beep every 0.5 seconds

     Environment
    Operating Humidity
    0~95% RH at 0~40°C (Non-condensing)
    Audible Noise
    Less than 40 dB
    * Specifications are subject to change without further notice

    * Specifications are for reference, actual information should be based on real product

     Document
    　Catalog  　



    POWERCOM ALN UPS, provide simulated sine wave output for connected application is the best choice for Office and Home application. ALN UPS is a product specially designed for Personal Computer. It’s inter-embedded design are light and space saving. ALN provides stable power to computer and monitor simultaneously. When power failure occurred, critical back-up power ensures smooth transition and sufficient time for user to secure important data. ALN designs with green power saving feature, synchronize start up / shutdown with computer operation. Eliminate all unnecessary power waste during computer offline. ALN UPS supports UPSMON monitoring system. With USB connection, administrator can remotely monitor UPS status and schedule UPS timed-event through web browser.
