UPS
Model		MAC1000TIN	MAC1500TIN	MAC2000TIN	MAC3000TIN
		MAC1000TEN	MAC1500TEN	MAC2000TEN	MAC3000TEN
Capacity(VA)		1000 VA	1500 VA	2000 VA	3000 VA
Capacity(Watts)		1000 W	1500 W	2000 W	3000 W
Form		Tower Type
Phase		Single Phase
Energy Saving		Yes - ECO Mode Efficiency > 94%
INPUT
Voltage		100 / 110 / 120 /127 or 208 / 220 / 230 / 240 VAC
Voltage Range		60 - 144 Vac, < 25% Load    120 - 276 Vac, < 25% Load 70 - 144 Vac, < 50% Load    140 - 276 Vac, < 50% Load 80 - 144 Vac, < 75% Load    160 - 276 Vac, < 75% Load 90 - 144 Vac, < 100% Load    180 - 276 Vac, < 100% Load
Frequency Range		50 / 60 Hz (Auto Sensing)
Power Factor		> 0.97
Cold Start		Yes
OUTPUT
Rated Power Factor		1.0
Waveform		Pure Sine Wave
Voltage		100 / 110 / 115 / 120 / 127 VAC ± 2% or 208* / 220 / 230 / 240 VAC ± 2%
Frequency		50 / 60 Hz ± 0.25 Hz
Transfer Time		0 ms
Harmonic Distortion		≤2.5% THD at Linear Load
Crest Factor		3 : 1
EPO Function		Yes
PROTECTION
Overload	Line Mode	105% - 120% for 30 seconds 121% - 150% for 10 seconds
	Battery Mode	101% - 109% for 10 seconds 110% - 120% for 3 seconds
Surge Protection		IEC 61000-4-5 Level 3
Bypass		Internal Bypass(Automatic and Manual)
Short Circuit Protection		UPS Output Cut Off Immediately
BATTERY
Type		12V 9Ah	12V 7Ah	12V 7Ah	12V 9Ah
Quantity		2	4	6
Sealed, Maintenance Free		YES
Typical Recharge Time		4 Hr to 90%
MANAGEMENT & COMMUNICATION
Indicator		LCD Control Panel
Communication Port		RS232, USB B-type
SNMP Slot		Yes
Audible Alarms		Yes
PHYSICAL
Dimensions(WxDxH)(mm)		144 x 357 x 228	191 x 406 x 327
Weights(Kgs)		10.4	16.4	20.3	22.9
Shipping Dimensions(mm)		249 x 448 x 359	292 x 500 x 455
Shipping Weights(Kgs)		11.5	18.4	22.3	24.9

* While 208V output, capacity will derated to 90%

* Specifications are subject to change without further notice

* Specifications are for reference, actual information should be based on real product
