PRODUCT  >>  ON - Line  >> Sentinel

   SNT - Sentinel

  • Sine Wave Output with Power Factor 1.0

  • Low THD suitable for delicate instruments

  • Diagram LCD with auto-rotation

  • EPO shutdown during critical times

  • Multi-Section fan keeps UPS at high efficiency

  • Overload, Surge, Short Circuit Protection

  • SNT - 1000 / 1500 / 2000 / 3000 / 6000 / 10K

  •  UPS
    Model
    SNT-1000
    SNT-1500
    SNT-2000
    SNT-3000
    SNT-6000
    SNT-10K
    Capacity(VA)
    1000 VA
    1500 VA
    2000 VA
    3000 VA
    6000 VA
    10KVA
    Capacity(Watts)
    1000 W
    1500 W
    2000 W
    3000 W
    6000 W
    10KW
    Form
    Rack and Tower Type
    Phase
    Single Phase
    Energy Saving
    Yes - ECO Mode Efficiency > 94%

     INPUT
    Voltage
    208 / 220 / 230 / 240 VAC
    Voltage Range
    120 - 300 VAC, < 25% Load
    140 - 300 VAC, < 50% Load
    160 - 300 VAC, < 75% Load
    180 - 300 VAC, < 100% Load
    Frequency Range
    50 / 60 Hz (Auto Sensing)
    Power Factor
    > 0.98
    > 0.97
    Cold Start
    Yes

     OUTPUT
    Rated Power Factor
    1.0
    Waveform
    Pure Sine Wave
    Voltage
    *208 / 220 / 230 / 240 VAC ± 2%
    *200 / *208 / 220 / 230 / 240 VAC ± 2%
    Frequency
    50 / 60 Hz ± 0.25 Hz
    Transfer Time
    0 ms
    Harmonic Distortion
    ≤ 2.5% THD at Linear Load
    ≤ 3% THD at Linear Load
    Crest Factor
    3 : 1
    Load segment
    Yes
    EPO Function
    Yes

     PROTECTION
    Overload Line Mode
    105% - 120% for 30 seconds
    121% - 150% for 10 seconds
    Battery Mode
    101% - 109% for 10 seconds
    110% - 120% for 3 seconds
    Surge Protection
    >1620J
    IEC 61000-4-5 Level 3
    Bypass
    Internal Bypass(Automatic and Manual)
    Short Circuit Protection
    UPS Output Cut Off Immediately

     BATTERY
    Model
    SNT-1000
    SNT-1500
    SNT-2000
    SNT-3000
    SNT-6000
    SNT-10K
    Type
    12V 7Ah
    12V 9Ah
    12V 7Ah
    12V 9Ah
    12V 5Ah
    12V7Ah : Option(3U)
    12V 9Ah
    Intermal Batt.
    Yes
    External Batt.
    Quantity
    3
    6
    20
    Sealed, Maintenance Free
    YES
    Typical Recharge Time
    4 Hr to 90%
    External Battery Cabinet
    Option
    External Battery Connector
    Option

     MANAGEMENT & COMMUNICATION
    LCD Control Panel
    Yes
    Communication Port
    RS232, USB(B-type)
    SNMP Slot
    Yes
    Audible Alarms
    Yes

     PHYSICAL
    Power Module Dimensions(WxDxH)(mm)
    428 x 425 x 84
    428 x 635 x 84
    Weights(Kgs)
    15.8
    17.3
    28.5
    31.3
    15.8
    20
    Shipping Dimensions(mm)
    546 x 552 x 206
    550 x 750 x 220
    Shipping Weights(Kgs)
    18.6
    20.1
    32.3
    35.7
    19.6
    24
    Battery Module Dimensions(WxDxH)(mm)
    428 x 425 x 84
    428 x 635 x 84
    428 x 635 x 84 (2U)
    428 x 597 x130(3U)
    428 x 657 x 130 (3U)
    Weights(Kgs)
    20.7
    37.3
    42(2U) / 66(3U)
    68
    Shipping Dimensions(mm)
    546 x 552 x 206
    550 x 750 x 220
    500 x 750 x 220(2U)
    560 x 740 x 375(3U)
    590 x 830 x 370
    Shipping Weights(Kgs)
    23.4
    40.8
    45.6(2U) / 75.5(3U)
    83
    * While 208V output, capacity will derated to 90%

    * Specifications are subject to change without further notice

    * Specifications are for reference, actual information should be based on real product

     Document
     Catalog - 1
     Catalog - 2
     User Manual - 1
     User Manual - 2
     Monitoring
     UPSMON-Pro Windows
     UPSMON-Pro Linux
     SNMPCard - DA807
     Modbus - NET485
     DryContact - AS400
     Tool - UPS FW Upgrade V2.1



    POWERCOM SNT On-Line UPS outputs pure sine wave with Power Factor 1.0, which is suitable for delicate electronic equipment.SNT UPS equipped with LCD display, users can acquire UPS information instantly from the front panel. SNT intelligent fan system automatically adjusts fan speed base on power load, maintains optimal temperature control and noise emission.SNT has multiple sockets, allowing users to use multiple loads at the same time, increasing the usability. Overall, SNT series combine with high-tech design, clear LCD indicator and portable device UPS monitor, which is the best choice of safe-guard for server room, data center, storage equipment and network equipment.
