MAC- Macan comfort


  • Power Factor 1.0 for Larger Power Density

  • Pure Sinewave Output with Double Conversion Topology

  • Extremely Low THD suitable for Delicate Instruments

  • Diagram LCD for better status indication

  • Six section fan regulation for varied loading

  • Overload, Surge, Short Circuit Protection

  • MAC - 1000 / 1500 / 2000 / 3000 / 6000 / 10KVA

    •
     UPS
    Model
    MAC-1000
    MAC-1500
    MAC-2000
    MAC-3000
    MAC-6000
    MAC-10000
    Capacity(VA)
    1000 VA
    1500 VA
    2000 VA
    3000 VA
    6000 VA
    10000 VA
    Capacity(Watts)
    1000 W
    1500 W
    2000 W
    3000 W
    6000 W
    10000 W
    Form
    Tower Type
    Phase
    Single Phase
    Energy Saving
    Yes - ECO Mode Efficiency > 94%

     INPUT
    Voltage
    100 / 110 / 120 or 208 / 220 / 230 / 240 Vac
    208 / 220 / 230 / 240 Vac
    Voltage Range
    60 - 144 Vac, < 25% Load    120 - 276 Vac, < 25% Load
    70 - 144 Vac, < 50% Load    140 - 276 Vac, < 50% Load
    80 - 144 Vac, < 75% Load    160 - 276 Vac, < 75% Load
    90 - 144 Vac, < 100% Load    180 - 276 Vac, < 100% Load
    120 - 276 Vac, < 25% Load
    140 - 276 Vac, < 50% Load
    160 - 276 Vac, < 75% Load
    180 - 276 Vac, < 100% Load
    Frequency Range
    50 / 60 Hz (Auto Sensing)
    Power Factor
    > 0.97
    Cold Start
    Yes

     OUTPUT
    Rated Power Factor
    1.0
    Waveform
    Pure Sine Wave
    Voltage
    100* / 110* / 120 / 127 VAC ± 2% or 208* / 220 / 230 / 240 Vac ± 2%
    208* / 220 / 230 / 240 Vac ± 2%
    Frequency
    50 / 60 Hz ± 0.25 Hz
    Transfer Time
    0 ms
    Harmonic Distortion
    ≦ 2.5% THD at Linear Load
    Crest Factor
    3 : 1
    EPO Function
    Option

     PROTECTION
    Overload Line Mode
    105% - 120% for 30 seconds
    121% - 150% for 10 seconds
    Battery Mode
    101% - 109% for 10 seconds
    110% - 120% for 3 seconds
    Surge Protection
    IEC 61000-4-5 Level 3
    Bypass
    Internal Bypass(Automatic and Manual)
    Short Circuit Protection
    UPS Output Cut Off Immediately

     BATTERY
    Type
    12V 9Ah
    12V 7Ah
    12V 7Ah
    12V 9Ah
    12V 7Ah
    12V 9Ah
    Quantity
    2
    4
    6
    6
    20
    20
    Sealed, Maintenance Free
    YES
    Typical Recharge Time
    4 Hr to 90%
    External Battery Cabinet
    Option
    12V 7Ah*6, 24Vdc
    12V 7Ah*8, 48Vdc
    12V 7Ah*12, 72Vdc
    12V 7Ah*20, 240Vdc
    12V 9Ah*20, 240Vdc
    External Battery Connector
    Option

     MANAGEMENT & COMMUNICATION
    LCD Control Panel
    YES
    Communication Port
    RS232, USB(B-type)
    SNMP Slot
    Option
    Audible Alarms
    YES

     PHYSICAL
    Dimensions(WxDxH)(mm)
    144 x 357 x 228
    191 x 406 x 327
    257 x 590 x 570
    Weights(Kgs)
    10.4
    16.4
    20.3
    22.9
    78
    88.4
    Shipping Dimensions(mm)
    249 x 448 x 359
    292 x 500 x 455
    380 x 710 x 735
    380 x 710 x 735　
    Shipping Weights(Kgs)
    11.5
    18.4
    22.3
    24.9
    87
    97.4
    * While 208V output, capacity will derated to 90%

    * While 100V input, capacity will be derated to 80% for 1.5K/2K/3K LV model

    * While 110V input, capacity will be derated to 90% for 1.5K/2K/3K LV model

    * Specifications are subject to change without further notice

    * Specifications are for reference, actual information should be based on real product

     Document
    　Catalog  　
    　User Manual - 1  　
    　User Manual - 2  　
    　Certification  　
    　Test Report - SNMP  　
    　Test Report - Modbus  　
     Monitoring
    　Upsmon Pro Windows  　
    　Upsmon Pro Linux  　
    　SNMPCard - DA807  　
    　Modbus - NET485  　
    　DryContact - AS400  　
    　Tool - Firmware Upgrade  　



    POWERCOM MAC Online UPS series provide pure sine wave output for electronic devices. MAC online UPS are design as the safe guard of high-class computer, data center and server. MAC series contain power factor 1.0, output pure sinewave and double conversion topology, brings up great quality output and UPS performance. MAC series added Diagram LCD Display and Six sections Fan Regulation for information indication directly and operating environment quietly, upgrades user experience and working quality. POWERCOM MAC series combine with high tech design and better model performance is the best choice for high-class computer, data center and server.
