VGS- Vanguard II


  • On-Line UPS Design and Pure Sinewave Output

  • Double Conversion and High Efficiency Mode

  • Advance Battery Management (ABM)

  • Overload, Surge, Short Circuit Protection

  • Design for Advance Missional Electronic Device

  • Tower Type Design and Free-Run Mode

  • VGS-1000 / 1500 / 2000 / 3000 / 6000 / 10KVA

  •
     UPS
    Model
    VGS-1000
    VGS-1500
    VGS-2000
    VGS-3000
    VGS-6000
    VGS-10000
    Capacity (VA)
    1000
    1500
    2000
    3000
    6000
    10000
    Capacity (Watts)
    900
    1350
    1800
    2700
    5400
    9000
    Form
    Tower
    Phase
    Single Phase
    Energy Saving
    Yes - ECO mode Efficiency > 94%

     INPUT
    Voltage
    100 / 110 / 115 / 120 / 127 or 208 / 220 / 230 / 240 Vac
    208 / 220 / 230 / 240 Vac
    Voltage Range 110 Vac
    60 ~ 144 Vac < 25% Load
    70 ~ 144 Vac < 50% Load
    80 ~ 144 Vac < 75% Load
    90 ~ 144 Vac < 100% Load
    120 ~ 276 Vac < 25% Load
    140 ~ 276 Vac < 50% Load
    160 ~ 276 Vac < 75% Load
    180 ~ 276 Vac < 100% Load
    220 Vac
    120 ~ 276 Vac < 25% Load
    140 ~ 276 Vac < 50% Load
    160 ~ 276 Vac < 75% Load
    180 ~ 276 Vac < 100% Load
    Frequency Range
    50 / 60 Hz (Auto Sensing)
    Power Factor
    > 0.97
    Cold Start
    Yes

     OUTPUT
    Rated Power Factor
    0.9
    Waveform
    Pure Sine Wave
    Voltage
    100 / 110 / 115 / 120 / 127 or 208 / 220 / 230 / 240 Vac ± 2%
    208 / 220 / 230 / 240 Vac ± 2%
    Frequency
    50 / 60 Hz ± 0.25 Hz
    Transfer Time
    0 ms
    Harmonic Distortion
    ≦ 2.5% THD at Linear Load
    ≦ 3% THD at Linear Load
    Crest Factor
    3 : 1
    EPO Function
    Yes

     PROTECTION
    Overload Line Mode
    105% - 120% for 30 seconds
    121% - 150% for 10 seconds
    Battery Mode
    101% - 109% for 10 seconds
    110% - 120% for 3 seconds
    Surge Protection
    IEC 61000-4-5 Level 3
    Bypass
    Internal Bypass(Automatic and Manual)
    Short Circuit Protection
    UPS Output Cut Off Immediately

     BATTERY
    Model
    VGS-1000
    VGS-1500
    VGS-2000
    VGS-3000
    VGS-6000
    VGS-10K
    Type
    12V 7Ah
    12V 7Ah
    12V 7Ah
    12V 7Ah
    12V 7Ah
    12V 9Ah
    Quantity
    3
    4
    6
    8
    20
    20
    Sealed, Maintenance Free
    YES
    Typical Recharge Time
    4 Hr to 90%
    External Battery Module
    Option
    External Battery Connector
    Option

     MANAGEMENT
    Indicator
    LCD Control Panel
    Communication Port
    RS232, USB(B-type)
    SNMP Slot
    Option
    Audible Alarms
    YES

     PHYSICAL
    Power Module
    Dimensions
    (WxDxH)
    152 x 420 x 237
    152 x 500 x 241
    200 x 420 x 358
    257 x 590 x 570
    257 x 690 x 585
    Weights
    (Kgs)
    15.2
    19.4
    28.8
    30
    86
    96.5
    Shipping Dimensions
    (WxDxH)
    280 x 545 x 355
    280 x 625 x 356
    340 x 526 x 485
    415 x 760 x 800
    408 x 860 x 800
    Weights
    (Kgs)
    17.4
    21.3
    31.6
    32.9
    93.5
    112
    * While 208V output, capacity will derated to 90%

    * Specifications are subject to change without further notice

    * Specifications are for reference, actual information should be based on real product

     Document
     Catalog
     Certification
     Certification
     Monitoring
     Upsmon Pro Windows
     Upsmon Pro Linux
     SNMPCard - CY504
     SNMPCard - BY506
     Modbus - NET485
     DryContact - AS400



    POWERCOM VGS online series with high performance power output and curve shape outfit is the best choice for business, IT and Telecom system. High performance VGS series power factor 0.9 and attached with PFC (Power Factor Correction) stabilize fluctuate voltage, including over voltage, lower voltage and provide clean and stable voltage for critical device. POWERCOM VGS online series with easy-reading LCD indicator, clearly shows up UPS status and easy to operate. VGS series attach with selectable mode offers different application for user, such as high efficiency mode, free run mode. POWERCOM VGS online series with high performance power factor 0.9 and multi-function design are the best choice for business, IT and telecom system.
