INF - INF


  • High efficiency inverter

  • Pure sine wave output

  • Battery connect extendable

  • Automatic voltage regulator(AVR)

  • Clear LCD indicator

  • Overload, surge, short circuit protecion

  •
     UPS

    Model
    INF-500A
    INF-800A
    INF-1100A
    INF-1500A
    INF-500AP
    INF-800AP
    INF-1100AP
    INF-1500AP
    Capacity(VA)
    500 VA
    800 VA
    1100 VA
    1500 VA
    Capacity(Watts)
    300 W
    480 W
    770 W
    1050 W
    Form
    Tower Type

     INPUT
    Voltage
    100 / 110 / 120 or 220 / 230 / 240 Vac
    Voltage Range
    70 - 150 or 140 - 300 Vac
    Frequency Range
    50 / 60 Hz (Auto Sensing)

     OUTPUT
    Waveform
    Pure Sine Wave
    Voltage
    100 / 110 / 120 or 220 / 230 / 240 Vac
    Frequency
    50 / 60 Hz ± 1 Hz
    Transfer Time
    2 - 4 ms(Typical)

     PROTECTION
    Full Protection
    Overload, Surge, Short Circuit

     MANAGEMENT & COMMUNICATION
    Indicator
    LED Panel, LCD Panel
    Communication Port
    USB B-type (AP Model)

     PHYSICAL
    Dimensions(WxDxH)(mm)
    130 x 412 x 200
    Weights(Kgs)
    5.8
    7.2
    10.8
    12.2
    Shipping Dimensions(mm)
    253 x 488 x 321
    Shipping Weights(Kgs)
    7.3
    8.7
    12.3
    13.7

     Alarm
    Overload / Fault
    Continuous Beeping
    Battery Mode
    Beep every 2 seconds
    Low Battery
    Beep every 0.5 seconds

     Environment
    Operating Humidity
    0~90% RH at 0~40°C (Non-condensing)
    Audible Noise
    Less than 50 dB

     Battery (Recommended Form)
    Voltage
    12 VDC
    24 VDC
    Battery Capacity
    65 Ah - 200 Ah
    100 Ah - 200 Ah
    Maximum Charge Current
    10 A
    15 A
    Discharge Protection
    Auto Diagnostics, Over - Discharge, Shot Circuit, Fuse
    * Specifications are subject to change without further notice

    * Specifications are for reference, actual information should be based on real product

     Document
     Catalog
     Certification



    POWERCOM INF Inverter series with compact size, provide long back up time to essential model, is the best choice for home, office and workstation. INF series are the model with Auto Voltage Regulator (AVR) stabilize fluctuate voltage including over-voltage, under-voltage and other fluctuate voltage problem and output with clean and stable voltage for essential device. POWERCOM INF Inverter series provide pure sinewave output and huge current battery connectable to support long time power back-up. Audible noise reminder and clear LED display are attached with INF series. POWERCOM INF series UPS prolongs power back time creates longer protection to critical device, is the best choice for Home, Office and Telecom System.
